Simplex Rls302 Low-Profile Hydraulic Cylinder — 30-Ton Capacity, 62 Mm Stroke

Description

Simplex RLS302 30 ton (266,9 kN) Capacity, 2.44 in (62 mm) Stroke, Single-Acting, Low Height Hydraulic Cylinder

Features:

• Compact low-profile design.
• HD spring for fast retraction.
• Grooved plunger to stabilize the load.
• Stop ring for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt

Specifications:Maximum Operating Pressure10,000 psi (700 bar)Capacity Class30 tonnageCapacity30 imperial tons (266,9 kN)Stroke2.44 in (62 mm)Collapsed Height A4.62 in (117.3 mm)Extended Height B7.06 in (179,3 mm)Return TypeSingle-Acting, Spring ReturnPlunger TypeSolidMaterialSteelCylinder Effective Area6.49 in² (41,9 cm²)Oil Capacity Required15.8 in³ (258,9 cm³)Ram Bore Diameter2.87 in (72,9 mm)Pressure at Capacity9250 psi (638 bar)Weight15.0 lbs (6,8 kg)
